Rubber Hose

Rubber Hose

Rubber hose designed to support flexible shaft to transfer power and protect flexible shaft meanwhile. The wear-resistance, bending-resistance, aging-resistance performance are quite important to a good rubber hose. The natural rubber content, material composition and processing technique will determine the quality level of a finished rubber hose.
inquiry

DETAILS

  • Rubber Hose
  • Rubber Hose
  • Rubber Hose

Rubber hose designed to support flexible shaft to transfer power and protect flexible shaft meanwhile. The wear-resistance, bending-resistance, aging-resistance performance are quite important to a good rubber hose. The natural rubber content, material composition and processing technique will determine the quality level of a finished rubber hose.

T-FLEX could supply Economic rubber hoses and High-end environmental-friendly rubber hoses.


Optional supplying

1, Strip steel material could be 40Mn or 65Mn

2, Steel wire braid could be 1 or 2 layers

3, Outer tensile strength at break could be chose



Advantage

MORE VALUE:

HIGH-END ENVIRONMENTAL-FRIENDLY RUBBER HOSE

In order to meet European and American market environmental protection regulation, we added a special production line and designed particular composition to make environmental-friendly rubber hoses. After dozens of tests, finally we develop the high-end environmental-friendly rubber hose with complying with RoHS, PAHs, Reach, TSCA, CP65, etc.

If you want the REAL environmental-friendly rubber hoses, T-Flex is the one you need to contact immediately

parameters

Outer Diameter (mm)

16

20

22

24

25

30

32

36

38

42

Inner Diameter (mm)

9

10

10

13

15

16

18

20

21

25

Outer Tensile Strength at Break(N/cm2)

>1000

>1000

>1000

>1000

>1000

>1000

>1000

>1000

>1000

>1000

Inner Adhesive Force (N/cm2)

50-60

50-60

50-60

60-65

60-65

60-65

60-65

60-65

60-65

60-65

Strip Steel Material

40Mn or 65Mn

Strip Steel Hardness (HRC)

20-30

20-30

20-30

25-30

25-30

25-30

25-30

25-30

25-30

25-30

Rubber Hardness (SHA)

75-80

Steel Wire Braid

1 or 2 layers (96pcs or 120pcs wires per layer)

Minimum Bending Radius (mm)

According to customer's need
